Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: XC
  • Model Number: CFD-16
  • Type: Other food processing machinery
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Name:: chocolate factory machines in china
  • Power: 380v50Hz
  • Film width: 680mm

Packaging & Delivery

Packaging Details Cover with the film and pack into a wooden case , reach international standard
Customer's special requirement is available
Delivery Time 2 month

XC-16 automatic dip stick chocolate cup filling sealing machines



Product Information :

Cup diameter : 55 mm ( can be change according to your request )

Chocolate weight : 3- 6g

Biscuit bar : < 3.5mm length

Biscuit bar qty : 16-20pcs



Feature :

  1. Full automatics working process .

  2. Running automatically from cup feeding filling, sealing, cutting , to discharging

  3. PLC control with touch screen , very easy to operate ,

  4. Alarm error system

  5. Easy installation, Immediate commissioning (done within 2 days)

  6. High cost efficiency



Technical Information :

Model :

CFD-4

CFD-8

CFD-16

Speed (Cup / hour )

Normal output : from 15 to 20 cycles/minute (depending on the container size and filling weight )

3,000 -4,000

8,000 -10,000

10,000-15,000

Max.air comsumption

0.6-0.8m3/min

0.8-1.2m3/min

1.2-1.5m3/min

Air Pressure :

0.6Mpa—0.8Mpa

0.6Mpa—0.8Mpa

0.6Mpa—0.8Mpa

Electrical power

220/380

220/380

220/380

Motor power

0.75KW

1.5KW

1.5KW





Full Working Process



  1. Pneumatic cup feeding automatically

  2. Auto 1st time biscuit ball feeder

  3. Auto 2ed time biscuit ball feeder

  4. Manually put moon tray

  5. Moon tray adjust device auto

  6. Auto fill chocolate paste

  7. Auto batch code printings

  8. Auto charge film with photo cell track

  9. Auto 2 times hot sealing,

  10. Auto Cutting unit

  11. Waste film can be collected automatically.

  12. Auto mechanical hand outfeed with conveyor



YOU TUBE LINK

CFD-16 dip stick chocolate machine

https://youtu.be/frHwGfepHPY







Contact Information :



Ms Kathy J.

Mobile / What’sapp / Wechat /Viber : +86-138 0271 4343

Tel:         +86-754-8821 8350

Fax:              +86-754-8811 6350

Skype:   xinchuangfoodmahcine



Website : http://www.pack-machinery.com/







XINCHUANG-Your Solution Partner For Food Packaging Machinery
