Quick Details

  • Type: Other
  • Condition: New
  • Application: Beverage, Chemical, Food, Medical, other food processing machinery
  • Packaging Type: Case, Film
  • Packaging Material: Plastic, Wood
  • Automatic Grade: Automatic
  • Driven Type: Pneumatic
  • Voltage: 380v50hz
  • Power: 0.75kw
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: XINCHUANG
  • Model Number: CFD -6
  • Weight: 2500 KGS
  • Dimension(L*W*H): 3500*800*1700mm
  • Certification: CE
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Name:: mineral water cup filling&sealing machine
  • Color:: light gun color
  • Material:: SS#304 stainless steel /Carton steel
  • OEM:: Yes
  • Diameter of cup: changable
  • Warranty: one year
  • Cups shape: Round
  • Filling volumn: 50-400 ml
  • Time mode: Servo motor dirving
  • Film width: 320 mm

Packaging & Delivery

Packaging Details Cover with the film , then pack into wooden case
one machine load in a 20ft container
Delivery Time 1month

 Shantou XC filling   machine

mineral water cup filling  and sealing machine
1.Fully automatic
2. SS#304 materails
3. Meet up Hygienic&Sanitary standard





Feature :

a.      Automatics working process .Running automatically from cup feeding filling, sealing, cutting , to discharging, Humidified Operation !

b.      High Speed 10,000 pcs per hour , It's a necessity in mass production line

c.      Space saving design and packing film materials saving desing

c.      Integration of electro-pneumatic cabinets

d.      Simplified Human/Machine Interface: only start and stop buttons, standard PLC control, with Alarm error system

e.      Operator-friendly working height (Web level at 1050 mm)

f.       Easy accessibility

g.      Immediate commissioning (done within 2 days)

h.      High cost efficiency

i.       The machine fascinates by its compact design, quick implementation,

j.       simplified servicing and strikingly decreased floor space requirement.



Capacity

5,000 – 6,500 pcs / hour,

The cavity of mould : 6X 1



Technical Details

Normal output : from 15 to 20 cycles/minute (depending on the container size and filling weight )

Cup Size: 30mm ( Inner diameter )

Filling Range: 15-40ml

Film Width: 420mm



Electricity

Supply 3 × 380 V (220 V if possible)

Consumption 25–35 KVA tri. (according to machine options)



Compressed Air

Supply min. 5 bar, max.8 bar

Consumption 100–145 Nm3/h (according to machine options)





Full Working Process

Auto Cup Feeder – Auto Filler – Auto  put foil lid– 2 times Hot Sealing – Out feed – Waste Film Collection







Contact Information :



Ms Kathy J.

Mobile / What’sapp / Wechat /Viber : +86-138 0271 4343

Tel:            +86-754-8821 8350

Fax:           +86-754-8811 6350

Mobile :     +86-138 0271 4343

Skype:       xinchuangfoodmahcine



Website : http://www.pack-machinery.com/





XINCHUANG-Your Solution Partner For Food Packaging Machinery
