Quick Details

  • Type: Filling Machine
  • Condition: New
  • Application: Beverage, Food
  • Packaging Type: Bags, Pouch, Stand-up Pouch
  • Packaging Material: Plastic
  • Automatic Grade: Automatic
  • Driven Type: electric & pneumatic
  • Voltage: 380V 50Hz
  • Power: 3.5 kw
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: XC
  • Model Number: CFR-6
  • Dimension(L*W*H): 2450*1510*2200mm
  • Weight: 1800kg
  • Processing: automatic rotary filling capping machine
  • Material: SS#304
  • Processing type: chocolate,drinking water,jelly,milk,juice
  • Filling head: 6 heads

Packaging & Delivery

Packaging Details wooden case

 liquids chocolate filling machine in the spout cap tube
1. 10g chocolate
2. 6,000 pcs per hour
3. 6 filling heads
4. warmig tank









1. Description



  • A rotary chain type filling machine specially designed for Chocolate  tube filling and capping .
  • All new design.
  • The new technology of this machine is designed by our factory, which get the technical patent.
  • A highly automated filling and capping machine. The operation cycle, from filling, put the cap, screw the cap to product outfeed are fully automatically performed. It's a necessity in mass production line !
  • Suitable Containers : Standing up - pouch with cap
  • Suitable Packing Materials : Nylon Pouch / Metalized Pouch / Alumium Pouch
  • Available Products : chocolate tube / Juice / Drinking Water / Soybean milk / Drinking Jelly/ Drinking Chocolate / Oil / Washing Liquids /All kinds of Liquids





2. Technical Datas :



Modelzgx-6
Description :Auto Filling  & capping Machine
Packaging Speed :5,000-6,000 pcs / hour
Filling Volume :10--50 ml
Power :3-phase 4-line socket(380V50HZ)
Electric Machinery Power :1.1kw
Heat Up Power :10kw
Air Pressure :0.5Mpa—0.7Mpa
Max.Air Consumption :0.6m3/min
Timing Mode :Stepless speed regulating
Machine Dimension(L*W*H) :4000*1000*2000mm
Package Dimension(L*W*H) :4150*1150*2150mm
G.W. :2000 kg

Can be Customized machine.



3. Full Automatics Working Steps



1)

Hanging pouch by hand

2)

auto  filling

3)

 warming keep tank

4)

Load cap automatically

5)

Put the cap

6)

Screw cap

7)

Outfeed




We can make machine according to the customer's special requirements !
