Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: XC
  • Model Number: CFD-10
  • Type: food auto packaging machinery
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Filling content: 15-40ml
  • Timing mode: servo motor driving
  • Color: light gun color
  • Material: SS#304 stainless steel
  • OEM: YES
  • Film width: 320mm
  • Packaging speed: 10000-12000pcs/h
  • Voltage: 380V50HZ
  • Power: 1.5KW
  • Dimension: 12000x900x1700mm

Packaging & Delivery

Packaging Details 1.PVC THIN FILM PACKING
2.PACKED IN WOODEN CASE
3.IF ANY SPECIAL REQUIREMENTS,WE WILL PACK IT AS REQUESTED
Delivery Time 1 MONTH

CFD- three colors jelly / nata de coco automatic filling and sealing machinery







1. Description

  • A milk sealing machine specially desigd for Three colors jelly cup filling and sealing machine.
  • All new design.
  • The new technology of this machine is designed by our factory, which get the technical patent.
  • A highly automated soybean milk sealing machine. The operation cycle, from cup feeding, filling, sealing to product outfeed are fully automatically performed. It's a necessity in mass production line !





2. Technical data:



1)Model:CFD-10
2)Description:Three Colors Jelly Cup Auto Filling and Sealing machine
3)Packaging speed:10,000-12,000 pcs/hour
4)Filling volume:15-40ml
5)Power:3-phase 4-line socket(380V 50HZ)
6)Film width:320mm
7)Electric machinery power:1.5kw
8)Heat up power:6kw
9)Cooling power:7.5kw
10)Air pressure:0.5Mpa-0.7Mpa
11)Max air consumption:1.5m3/min
12)Timing mode:servo motor driving
13)Machine dimension(L*W*H):12000*900*1700mm
14)G.W.:4000kg







Can be Customized machine!!!





We have different model which can be choice for you as follows:



#ModelSpeed(pcs/hour)
1)CFD-43800-4800
2)CFD-1212,000-14,000









3. Full automatic working steps:



1)Auto feeder
2)first color jelly filling
3)through imported cooling system
4)second color jelly filling
5)through imported cooling system
6)third color jelly filling
7)charging film
8)2 times sealing
9)Cutting
10)Waste film auto collection
11)Outfeed




















XINCHUANG-Your Solution Partner For Food Packaging Machinery









Product show:





















Welcome to visit our factory at any time!
