New Product CFD-14 Honey Packing Machine

FOB Reference Price:Get Latest Price
$10,000.00 - $50,000.00 / Pieces | 1 Piece/Pieces (Min. Order)
Model Number:
CFD-14
Lead Time:
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 45 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Other food processing machinery
Automatic Grade:
Automatic
Production Capacity:
17000-21000 cups/h
Place of Origin:
Guangdong, China
Brand Name:
XC
Voltage:
380V50HZ
Power(W):
0.75KW
Dimension(L*W*H):
3000*800*1700MM
Weight:
1500 KG
Certification:
CE
Warranty:
one year
Name::
2014 New Product CFD-14 Honey Packing Machine
Color::
Light gun color
Material::
SS304 Stainless steel
Film width:
320mm
Filling content:
5-20ml
Heat up power:
4 kw
Air pressure:
0.5Mpa -0.7Mpa
Max air comsumption:
0.5m3/min
Timing mode:
Servo motor driving
OEM:
Yes
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
25 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Cover with the fim and a 3100*1000*1900MM wooden case
Port
any port of china
Lead Time :
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 45 To be negotiated



Product Description

2014 New Product CFD-14 Honey packing Machine is  specail design for  all kind o liquids ( honey )packing is fully auto filling and sealing .



* It is helpful for imporving  the production capacity , saving labor cost , then make sure factory's profit.







Feature



1.Suitable                    Containers

Plastic Cup , Bowl ,Box /Paper Cup ,

Bowl , Box .

2. Suitable Packing MaterialsNylon Film / Metalized Film /Alumium Film



3. Available ProductsJelly ,Soybean Milk , Milk tea , Drinking Water /Yogurt / Juice /All kind of Liquids




Techincal Datas



ModelCFD-14
Packing Speed18800-22000pcs/h
 Film Width 320mm
 Filling Content 50-300ml
Power 380v50Hz/220v50Hz
Electric Machinery Power1.5kw
Heat Up Power12kw
Air pressure0.5Mpa -0.7Mpa
Max. Air Consumption1.5cube meter/min
Outline  Dimension5000*1200*1700mm(L*W*H)
Timing ModeServo Motor Driving
Gross WeightAprox3000kg
Certification available:Yes
Usage:  Filling and sealing





 Machine Operation  Cycle



 a.Cups feeding automately

 b.Flatting  Cups

 c. Two times Filling

 d. Charging film

 e. Two times hot sealing

 f. Products outfeed,at the same time , collect the waste film automatically





Main  Components

1.Gear Box

2. Servo Driving

3.PLC Control with Touch Screen

4.Normal Button Control

5. Pheumatic Control

6. Photoelectric Switch





Main Brand for Electrics and Pneumatics
